Inner conductor
Solid copper
Φ3.61 mm
Dielectric
Foam /Solid PE
Φ9.40 mm
Shield
Bonded aluminium foil
Φ9.55 mm
Outer conductor
Tinned copper braid
Φ10.3 mm
Sheath
PVC/PE
Φ12.7 mm
Impedance
50±3 Ohm
Nominal capacitance
79.7 pF/m
Velocity of propagation
70%
Insulation resistance
>5000 Mohm.Km
Inner conductor resistance
24.94 Ohm/Km
Outer conductor resistance
16.08 Ohm/Km
Operating temperature range
-40°C - +85 °C
Min.bending radius
25 mm
Frequency(MHz)
Attenuation (dB/100 m)
Max. Attenuation(dB/100ft)
30
6.5
2.0
50
8.4
2.6
150
14.6
4.5
220
17.7
5.4
450
25.5
7.8
900
36.5
11.1
1500
47.7
14.5
1800
52.5
16
2000
55.4
16.9
2500
62.4
19
3000
67.5
20.6
5800
93
28.3
