Inner conductor
Solid copper
Φ1.42 mm
Dielectric
Foam /Solid PE
Φ3.81 mm
Shield
Bonded aluminium foil
Φ3.94 mm
Outer conductor
Tinned copper braid
Φ4.50 mm
Sheath
PVC/PE
Φ6.01 mm
Impedance
50±3 Ohm
Nominal capacitance
79.4 pF/m
Velocity of propagation
84%
Insulation resistance
>5000 Mohm.Km
Inner conductor resistance
17.6 Ohm/Km
Outer conductor resistance
12.76 Ohm/Km
Operating temperature range
-40°C - +85 °C
Min.bending radius
30 mm
Frequency(MHz)
Attenuation (dB/100 m)
Max. Attenuation(dB/100ft)
30
4.4
1.3
50
5.7
1.7
150
9.9
3
220
12
3.7
450
17.3
5.3
900
24.8
7.6
1500
32.4
1800
35.6
10.9
2000
37.7
11.5
2500
42.4
12.9
3000
46.5
14.2
5800
66.8
20.4
