Inner conductor
Solid copper
Φ1.78 mm
Dielectric
Foam /Solid PE
Φ4.83 mm
Shield
Bonded aluminium foil
Φ4.98 mm
Outer conductor
Tinned copper braid
Φ5.72 mm
Sheath
PVC/PE
Φ7.62 mm
Impedance
50±3 Ohm
Nominal capacitance
78.8 pF/m
Velocity of propagation
85%
Insulation resistance
>5000 Mohm.Km
Outer conductor resistance
7.26 Ohm/Km
Operating temperature range
-40°C - +85 °C
Min.bending radius
38 mm
Frequency(MHz)
Attenuation (dB/100 m)
Max. Attenuation(dB/100ft)
30
3.5
1.1
50
4.5
1.4
150
7.9
2.4
220
9.6
2.9
450
13.8
4.2
900
19.9
6.1
1500
26
1800
28.7
8.7
2000
30.3
9.2
2500
34.2
10.4
3000
37.5
11.4
5800
54.2
16.5
