Inner conductor
Solid copper
Φ2.74 mm
Dielectric
Foam /Solid PE
Φ7.24 mm
Shield
Bonded aluminium foil
Φ7.39 mm
Outer conductor
Tinned copper braid
Φ8.13 mm
Sheath
PVC/PE
Φ10.29 mm
Impedance
50±3 Ohm
Nominal capacitance
101.1 pF/m
Velocity of propagation
85%
Insulation resistance
>5000 Mohm.Km
Inner conductor resistance
2.92 Ohm/km
Outer conductor resistance
5.41 Ohm/Km
Operating temperature range
-40°C - +85 °C
Min.bending radius
51 mm
Frequency(MHz)
Attenuation (dB/100 m)
Max. Attenuation(dB/100ft)
30
2.2
0.7
50
2.9
0.9
150
5
1.5
220
6.1
1.9
450
8.9
2.7
900
12.8
3.9
1500
16.8
5.1
1800
18.6
5.7
2000
19.6
6
2500
22.2
6.8
3000
24.8
7.6
5800
35.5
10.8
