Inner conductor
Solid copper
Φ4.47 mm
Dielectric
Foam /Solid PE
Φ11.56 mm
Shield
Bonded aluminium foil
Φ11.71 mm
Outer conductor
Tinned copper braid
Φ12.50 mm
Sheath
PVC/PE
Φ14.99 mm
Impedance
50±3 Ohm
Nominal capacitance
76.8 pF/m
Velocity of propagation
87%
Insulation resistance
>5000 Mohm.Km
Inner conductor resistance
1.7 Ohm/Km
Outer conductor resistance
3.9 Ohm/Km
Operating temperature range
-40°C - +85 °C
Min.bending radius
75 mm
Frequency(MHz)
Attenuation (dB/100 m)
Max. Attenuation(dB/100ft)
30
1.4
0.4
50
1.8
0.5
150
3.2
1
220
3.9
1.2
450
5.6
1.7
900
8.2
2.5
1500
10.9
3.3
1800
12.1
3.7
2000
12.8
2500
14.5
4.4
3000
15.7
4.8
5800
23.8
7.3
