BS 5467 Multicore XLPE SWA PVC 1.9/3.3kV Cable
BS 5467 Copper Conductor Multi Core SWA PVC 1.9/3.3kV Cable
BS 5467 Copper Conductor Multi Core SWA PVC 1.9/3.3kV Cable
Category | Details |
|---|---|
Application | Multi-core PVC cable with steel wire armour (SWA). Suitable for direct burial in free-draining soil conditions for fixed indoor and outdoor installations. |
Characteristics | |
Voltage Rating Uo/U | 1.9/3.3kV |
Temperature Rating | Maximum Operating: +90ºC Maximum Short-Circuit: +250°C |
Minimum Bending Radius | 12 x overall diameter |
Construction | |
Conductor | Class 2 stranded copper |
Insulation | XLPE (Cross-Linked Polyethylene) |
Separator | Polyester Tape |
Filler | PVC (Polyvinyl Chloride) |
Armour | SWA (Galvanized Steel Wire Armour) |
Outer Sheath | PVC (Polyvinyl Chloride) |
Core Identification | Brown, Black, Grey |
Sheath Colour | Black |
Standards | BS 5467, IEC 60502-1, EN 60228 Flame retardant to IEC/EN 60332-1 UV Resistant |
