Halogen Free Control Cable 300/500V
Application
These halogen-free, flame retardant cables are designed for use as measuring and control cable in machinery and plant construction, in building and air-conditioning systems, in warehousing and conveying systems, in ship-building and for renewable energy such as in the construction of wind turbines.
Standards
DIN VDE 0281 part 14
Construction
Conductor | Stranded bare copper, class 5 according to DIN VDE 0295/BS 6360/IEC 60228. |
Insulation | ?Halogen-free compound special polymer. |
Sheath | Halogen-free compound special polymer. |
Technical Data
Rated Voltage Uo/U (Um) | 300/500V |
Operating Temperatures | flexing: -30℃~+90℃; fixed: -40℃~+90℃ |
Minimum Bending Radius | flexing: 10×OD; fixed: 4×OD |
Flame Retardant | VDE 0482-332-1-2/DIN EN 60332-1-2/IEC 60332-1 |
Halogen Free | VDE 0482 part 267/DIN EN 50267-2-1/IEC 60754 |
Gases Corrosively | NF X 10-702 |
Smoke Density | VDE 0482 part 1034-1+2/IEC 61034-1+2/DIN EN 61034-1+2/BS 7622 part 1+2 |
Oil Resistant | Yes |
Ozone Resistant | Yes |
Silicone Free | Yes |
UV Resistant | Yes |
