HIFLEX LiSiCSi TP
Rated voltage:Uo/U 300/500V
Test voltage:3000V
Insulation resistance at +20° C:≥:(+20°C):≧200MΩx km
Bending radius:
stationary :15 x cable diameterØ
stationary:-50°C - 180°C
Flame retardant:IEC 60332-1
Halogen-free (combustion gas corrosivity): Test method in accordance with IEC 60754-1 /IEC 60754-2
Material list
Part No. | No.cores Xcross-sec. | Outer Øca. | Cop.weight | Weight ca. |
|---|---|---|---|---|
960702 | 2x2x0,5 | 120 | 11,8 | 171 |
960701 | 2x2x0,75 | 261 | 16,4 | 205 |
907215 | 8x2x1,5 | 344 | 26,1 | 680 |
