(N)SHÖU O/J - 0.6/1kV Cable
(N)SHÖU O/J - 0.6/1kV Cable: Flexible, Rubber-sheathed Submersible Pump Cable Engineered for Resilience, Safety, and Performance
(N)SHÖU O/J - 0.6/1kV Cable
APPLICATION | Flexible cable, rubber sheathed, suitable for mining applications alongside conveyor belts, for energy supply to equipment in movement, industrial apparatus, and submersed pumps. Resistant to abrasion, oils, and flame retardant. Suitable for indoor and outdoor applications. |
CHARACTERISTICS | Voltage Rating Uo/U: 0.6/1kV Test Voltage: 3kV Ambient Temperature: Fixed: -40°C to +80°C; Flexed: -25°C to +80°C Maximum Short Circuit Temperature: +250°C Minimum Bending Radius: Fixed: 4 × overall diameter; Flexed: 5 × overall diameter |
CONSTRUCTION | Phase Conductor: Class 5 flexible copper Insulation: Rubber compound Inner Sheath: Rubber compound Outer Sheath: Heavy duty rubber compound Sheath Colour: Black |
STANDARDS | VDE 0250 Part 812, VDE 0295, EN 60228 Flame Retardant according to IEC/EN 60332-1-2 |
In modern industry and mining, power supply cables must withstand demanding environments—whether submerged in water, laid along conveyor belts, or installed outdoors in harsh conditions. One of the most reliable solutions for these applications is the (N)SHÖU O/J - 0.6/1kV Cable, a flexible, rubber-sheathed submersible pump cable engineered for resilience, safety, and performance.
Advantages of the (N)SHÖU O/J - 0.6/1kV Cable
The cable’s construction and materials provide several operational benefits:
1. High Mechanical Strength
The heavy-duty rubber sheath offers superior resistance to abrasion, crushing, and external impacts, making it ideal for conveyor belt systems and mobile equipment.
2. Water and Submersion Resistance
Engineered for submersible pump applications, the cable maintains insulation integrity in salty, brackish, or fresh water, ensuring stable performance up to considerable depths.
3. Temperature Resilience
With a working range from -40°C to +80°C and a short-circuit limit of +250°C, it adapts to extreme climates, from freezing conditions to high-temperature industrial settings.
4. Oil and Chemical Resistance
The rubber compound protects against oils, greases, and industrial chemicals, making it suitable for heavy industry.
5. Safety and Compliance
Its compliance with international standards (VDE, EN, IEC) guarantees flame retardancy, electrical safety, and reliability, crucial for hazardous mining operations.
Usage Scenarios
The versatility of the (N)SHÖU O/J cable allows it to be deployed across multiple industries.
1. Submersible Pumps
The primary application is in submersible pump systems for mining, agriculture, and water treatment facilities. Its waterproof and durable construction ensures safe power transmission under water.
2. Mining Operations
Commonly used in open-cast and underground mines, the cable supplies power to conveyor belts, drilling machines, and mobile equipment, enduring mechanical stresses and abrasive conditions.
3. Industrial Machinery
Suitable for heavy-duty machinery requiring flexible power supply cables in motion, particularly where oils, vibrations, and external impacts are frequent.
4. Outdoor Installations
The robust rubber sheath resists UV radiation and weathering, making it reliable for prolonged outdoor use.
5. Marine and Dockside Applications
Effective in environments with salty or brackish water, the cable is deployed for floating docks, dredging equipment, and shipyards.
Frequently Asked Questions (FAQ)
1. What is the voltage rating of the (N)SHÖU O/J cable?
It is rated for 0.6/1kV, suitable for low- to medium-voltage power distribution in industrial and mining settings.
2. Can it be used in underwater applications?
Yes, it is specifically designed for submersible pumps and can withstand continuous immersion in fresh, salty, or brackish water.
3. How flexible is this cable?
With Class 5 copper conductors and a minimum bending radius of 4×OD fixed / 5×OD flexed, it is highly flexible for dynamic applications.
4. Does the cable resist oil and chemical exposure?
Yes. Its rubber compounds ensure resistance against oils, greases, and many industrial chemicals.
5. Is the cable flame retardant?
Yes. It complies with IEC/EN 60332-1-2, ensuring reduced fire propagation risk.
6. What industries use this cable most?
It is widely used in mining, marine, water treatment, heavy industry, and outdoor power installations.
7. How does it perform in extreme temperatures?
It can operate between -40°C and +80°C, withstanding short-circuit conditions up to +250°C.
The (N)SHÖU O/J - 0.6/1kV cable stands out as a flexible, robust, and safe power supply solution for submersible pumps, mining operations, and heavy industry. Its technical resilience, oil resistance, and flame-retardant properties make it indispensable in demanding environments.
From South African platinum mines to marine docks and industrial plants worldwide, this cable ensures efficiency, reliability, and safety. For companies seeking to reduce downtime, cut operational costs, and comply with international standards, the (N)SHÖU O/J cable remains a leading choice.
