Reeling Cables in South African Mining: Powering Operations with Durability and Safety

South Africa’s mining industry is a cornerstone of its economy, driving wealth through gold, platinum, coal, and diamond extraction. From the deep tunnels of the Witwatersrand to the open-pit mines of the Northern Cape, this sector relies on robust, reliable equipment to operate safely and efficiently in some of the world’s harshest environments. Among the critical components enabling this work are reeling cables, specially designed to power mobile and semi-mobile machinery while withstanding the rigours of constant coiling and uncoiling. These cables are vital for equipment like shuttle cars, stacker-reclaimers, and drilling rigs, ensuring uninterrupted operations in both underground and surface mining.

Reeling cables are engineered for flexibility, durability, and safety, adhering to stringent South African standards such as SANS 1520-1 and the National Regulator for Compulsory Specifications (NRCS). This article explores the design, materials, applications, and challenges of reeling cables in South African mining, providing a comprehensive guide to their role in powering the industry’s backbone. By addressing their construction, performance, and solutions to common issues, we highlight why reeling cables are indispensable in South Africa’s mining landscape.

Overview of Reeling Cables

Reeling cables are flexible, high-performance cables designed for repeated coiling and uncoiling on cable reels, making them ideal for mobile mining equipment that requires dynamic power delivery. Unlike trailing cables, such as the Type 61A, which are suited for semi-static applications where cables are dragged or repositioned occasionally, reeling cables are built to endure the mechanical stress of continuous reeling. This makes them essential for equipment that moves frequently, such as shuttle cars transporting coal or ore, stacker-reclaimers handling bulk materials, and drilling rigs used in exploration and extraction.

In South African mines, reeling cables are critical for maintaining operational efficiency in both underground and open-pit settings. Their ability to flex without breaking, resist environmental stressors, and deliver reliable power and control signals makes them a preferred choice for dynamic applications. Typically, these cables comply with SANS 1520-1 standards, ensuring they meet the safety and performance requirements for South Africa’s demanding mining conditions.

Design and Materials

The design of reeling cables is a feat of engineering, balancing flexibility, strength, and electrical performance to meet the unique demands of mining. Each component is carefully selected to ensure durability and safety under repeated mechanical stress and harsh environmental conditions.

Conductors: Reeling cables use tinned annealed copper conductors, classified as Class 5 per SANS 1411-1, for maximum flexibility. The tinning process coats the copper strands to prevent corrosion, which is critical in humid underground mines or chemically aggressive environments, such as those with acidic mine water. The fine stranding of Class 5 conductors allows the cable to bend and coil repeatedly without fracturing, ensuring reliable power delivery.

Insulation: The insulation material is typically Ethylene Propylene Rubber (EPR, type RD 3 as per SANS 1411-3), chosen for its excellent electrical properties, flexibility, and thermal stability. EPR can withstand temperatures ranging from -35°C to +90°C, making it suitable for South Africa’s diverse mining climates, from chilly underground tunnels to sun-exposed open pits. A triple-extruded semi-conducting screen is applied over the insulation to reduce electrical faults and electromagnetic interference (EMI), enhancing safety for operators and equipment.

Core Arrangement: Reeling cables feature a complex core arrangement to support both power and control functions. Typically, they include three power cores, three pilot cores for control signals, and one or more earth cores for grounding. These are laid up around a central strain-bearing element, such as a rubber filler or aramid fibre core, which absorbs tensile stress during reeling. This design ensures balanced power delivery and reliable control signals while maintaining structural integrity under mechanical strain.

Inner Sheath: The inner sheath, often made of polychloroprene (type RS 6, SANS 1411-3), provides mechanical protection and flexibility. Polychloroprene is tough yet pliable, allowing the cable to coil tightly without cracking. It also resists abrasion and impact, common in mining environments where cables may be dragged over rough surfaces.

Reinforcement: To withstand the tensile and torsional stresses of reeling, cables incorporate high-strength reinforcement, typically aramid or nylon braids. These materials provide exceptional tensile strength, preventing the cable from stretching or tearing during repeated coiling. A minimum of 16 nylon strings or equivalent aramid fibres is often used to ensure durability.

Outer Sheath: The outer sheath is typically made of polychloroprene or thermoplastic polyurethane (TPU). Both materials are highly resistant to abrasion, chemicals (e.g., oils, greases, and acidic water), and UV radiation, which is crucial for open-pit mines under South Africa’s intense sunlight. The sheath is also flame-retardant and, in some cases, low-smoke, reducing fire risks and ensuring safety in confined underground spaces.

Physical Characteristics: Reeling cables are designed for high flexibility to accommodate tight coiling radii, typically 4–6 times the cable diameter. They are also engineered to resist abrasion, impact, and environmental stressors like moisture, dust, and UV exposure, ensuring a long service life in South African mining conditions.

Performance Characteristics

Reeling cables are built to deliver reliable electrical and mechanical performance in the demanding conditions of South African mines.

Voltage Rating: Most reeling cables used in South African mining, such as Type 41, are rated at 0.64/1.1kV (phase-to-earth/phase-to-phase), suitable for low to medium-voltage equipment like shuttle cars and drilling rigs. Higher-voltage options, such as 3.8/6.6kV, are available for larger machinery like stacker-reclaimers, ensuring compatibility with diverse equipment.

Current-Carrying Capacity: The current-carrying capacity depends on conductor size and ambient conditions. For example, a 25 mm² reeling cable at 30°C ambient temperature can handle approximately 120–140 amps, sufficient for powering heavy mobile equipment. Proper sizing ensures the cable does not overheat during continuous operation.

Thermal Stability: Reeling cables operate effectively in temperatures from -35°C to +90°C, accommodating the extreme conditions of South African mines. The EPR insulation and polychloroprene/TPU sheaths maintain performance under thermal stress, whether in cold underground tunnels or hot open-pit sites.

Mechanical Durability: The cables are designed to withstand the mechanical stresses of reeling, including bending, twisting, and tension. The reinforcement and flexible conductors ensure durability, while the robust outer sheath protects against abrasion and impact from rough mine surfaces or equipment.

Applications in South African Mining

South Africa’s mining industry spans diverse environments, from deep underground gold and coal mines to vast open-pit operations for iron ore and diamonds. Reeling cables are critical for powering mobile and semi-mobile equipment in these settings.

Underground Mining: In underground mines, such as those in Mpumalanga’s coalfields or Gauteng’s gold mines, reeling cables power shuttle cars and continuous miners. Shuttle cars, used to transport coal or ore to conveyors, rely on reeling cables to deliver power and control signals while navigating tight tunnels. Continuous miners, which extract minerals in a continuous process, require cables that can coil and uncoil as the machine moves, with the Type 41 reeling cable being a common choice due to its flexibility and durability.

Open-Pit Minin: In open-pit operations, such as diamond mines in Limpopo or iron ore mines in the Northern Cape, reeling cables are used for mobile crushers, stacker-reclaimers, and drilling rigs. These machines require cables that can handle frequent movement and exposure to sunlight, dust, and abrasive surfaces. The UV-resistant and abrasion-resistant properties of reeling cables ensure reliable performance in these conditions.

Reel Management: Effective reel management is crucial for reeling cables. Cable reels must maintain proper tension to prevent overstretching or tangling, typically controlled by automated reeling systems. Cables are laid out to avoid sharp bends or dragging, using guides or rollers to minimize wear. In underground mines, cables are often suspended on insulators to protect them from machinery, while in open-pit mines, they are routed to avoid exposure to heavy traffic areas.

Safety and Compliance

Safety is paramount in mining, where electrical faults or fires can have catastrophic consequences. Reeling cables are designed with multiple safety features:

• Flame-Retardant and Low-Smoke Properties: The outer sheath is flame-retardant, reducing fire risks in confined underground spaces. Low-smoke materials minimize toxic fumes in case of fire, protecting workers.

• Robust Insulation and Screening: EPR insulation and semi-conducting screens prevent electrical faults, reducing the risk of shocks or arc burns. Tinned conductors resist corrosion, ensuring consistent performance.

• Compliance: Reeling cables comply with SANS 1520-1, ensuring they meet South African safety and performance standards. NRCS approval confirms adherence to regulatory requirements. International compatibility with IEC and SABS standards ensures interoperability with global mining equipment.

Challenges and Solutions (FAQ)

Q: How can wear from repeated reeling be prevented?

A: Wear is a common issue due to the mechanical stress of coiling and uncoiling. Solution: Use cables with durable TPU or polychloroprene sheaths and high-strength aramid/nylon reinforcement. Regular inspections for cuts, abrasions, or exposed conductors are essential. Replace damaged cables promptly and use proper reeling systems to maintain consistent tension.

Q: What causes overheating in reeling cables, and how can it be avoided?

A: Overheating can occur due to undersized conductors or high ambient temperatures. Solution: Select cables with appropriate conductor sizes based on current requirements (e.g., 25 mm² for 120–140 amps). Monitor ambient temperatures and ensure proper ventilation around reels. Use thermal monitoring systems to detect hot spots early.

Q: How do reeling cables handle chemical exposure in mines?

A: Mine environments often expose cables to oils, greases, and acidic water. Solution: TPU or polychloroprene sheaths provide excellent chemical resistance, while tinned copper conductors prevent corrosion. Regular cleaning to remove chemical residues extends cable life.

Q: How can tangling or overstretching be avoided during reeling?

A: Improper reel tension or cable routing can cause tangling or stretching. Solution: Use automated reeling systems with adjustable tension control. Install cable guides or rollers to ensure smooth coiling. Avoid exceeding the cable’s minimum bending radius (typically 4–6 times the diameter).

Q: What maintenance practices extend the life of reeling cables?

A: Solution: Conduct regular visual inspections for wear, use multimeters to check insulation resistance, and store spare cables in dry, shaded areas to prevent UV degradation. Clean cables to remove dust or chemicals, and ensure proper reel alignment to avoid uneven wear.

Conclusion

Reeling cables are the lifeblood of mobile mining operations in South Africa, powering critical equipment like shuttle cars, continuous miners, and stacker-reclaimers. Their sophisticated design, incorporating tinned copper conductors, EPR insulation, polychloroprene/TPU sheaths, and aramid/nylon reinforcement, ensures they can withstand the mechanical and environmental stresses of mining. Compliant with SANS 1520-1 and NRCS standards, these cables deliver safety and reliability in both underground and open-pit settings.

By addressing challenges like wear, overheating, and chemical exposure through durable materials and proper maintenance, reeling cables ensure operational efficiency and worker safety. As South Africa’s mining industry continues to evolve, choosing standards-compliant, high-quality reeling cables remains essential for powering the machinery that drives the nation’s mineral wealth.
