SANS Type 611 / 611-ECC 6.35/11 kV Mining Cables

Cable Types and Applications

SANS Type 611 Mining Cable

• Application: Designed for mining machinery and portable apparatus, particularly in hazardous underground and open-pit conditions.

• Voltage Rating: 6.35/11 kV (Uo/U).

• Key Use Cases: Section feeders, medium-sized draglines, large electric shovels, and rotary drills.

SANS Type 611-ECC Variant

• ECC (Earth Continuity Conductor): One pilot core is replaced with a tinned conductor. This provides enhanced earth fault current return capacity and improved grounding.

• Application: Mines where electrical protection, grounding, and safety monitoring are paramount.

Both types are integral to South African mining operations, where the rugged environment requires cables that can handle constant flexing, abrasion, and exposure to oil, sunlight, and water.

Benefits of SANS Type 611 and 611-ECC Cables

1. High Flexibility

            Suitable for constantly moving equipment such as draglines and shovels.

2. Durability in Harsh Environments

   • Resistant to oil, UV, sunlight, and abrasion.

   • Maintains integrity in both underground and surface mining.

3. Improved Electrical Safety

   • Pilot cores enable monitoring and protective relays.

   • ECC option provides enhanced earth fault protection.

4. Compliance with South African Standards

   • Meets SANS 1520-2 and NRCS requirements, ensuring safety and legal compliance in local mining operations.

5. Operational Efficiency

   • Reduces downtime due to cable failure.

   • Withstands mechanical stress, prolonging service life.

Usage Scenarios in South Africa

South Africa presents unique challenges in cable usage:

1. Underground Gold Mines (Witwatersrand Basin)

   • Extreme depth, high temperatures, and rock pressure.

   • Type 611-ECC cables used in section feeders for drills and pumps, providing reliable grounding.

2. Platinum Mines (Bushveld Complex)

   • Remote locations with high power demand.

   • Medium-voltage draglines powered by Type 611 cables due to flexibility and abrasion resistance.

3. Coal Mines (Mpumalanga)

   • Open-pit mining machinery such as shovels and conveyor systems.

   • Type 611 cables deliver efficient power with reduced downtime.

4. Case Example: Load-Shedding Preparedness

   • In 2024–2025, South Africa faced recurring load-shedding and power instability.

   • Mines increasingly relied on robust MV cables like Type 611/611-ECC to connect backup generators, ensuring uninterrupted operations.

Frequently Asked Questions (FAQ)

1. What is the difference between Type 611 and Type 611-ECC?
Type 611-ECC has one pilot core replaced with an earth continuity conductor, providing better grounding and fault current capacity.

2. Can Type 611 cables be used above ground?
Yes. With UV- and oil-resistant sheaths, they are suitable for both underground and surface mining.

3. What is the typical lifespan of these cables?
With proper handling and maintenance, service life can exceed 5–10 years in heavy-duty mining applications.

4. Are these cables flame retardant?
Yes, they comply with SANS 1411-1 and SANS 1411-3, offering flame resistance and self-extinguishing properties.

5. Why are pilot cores important?
They enable remote monitoring, earth leakage detection, and safety interlocks, reducing risks of accidents.

6. How do these cables support South Africa’s energy challenges?
By providing reliable medium-voltage connections to heavy machinery, backup systems, and renewable energy projects, ensuring mining operations remain stable during power shortages.

SANS Type 611 and 611-ECC 6.35/11 kV mining cables are not just technical products; they are critical enablers of South Africa’s mining and heavy industry sectors. Their combination of robust construction, compliance with SANS standards, electrical safety, and long-term durability makes them indispensable in a country where reliable energy infrastructure is essential.

As South Africa’s mining industry embraces electrification, digitalisation, and sustainability, these cables will continue to play a central role. From powering deep-level gold mines to ensuring uptime in platinum and coal operations, Type 611 and 611-ECC cables represent a trusted solution for one of the most demanding industrial environments in the world.
